16L Digital Sterilization Table Top Class N Autoclave Sterilization Equipments with Water Tank

Features:* SS304 chamber,one piece,without welding* SS304 tray and rack,the rack could be in two directions* Gasket is easy to be cleaned* Temperature digital display* Temperature deviation less than 0.5oC* Imported Italy Sirai Valve* 1800W heating elements, speed up the heating, more efficientTechnical Data:Details(16L) 1 Overall size (L *W*H) mm 440*580*390 2 Chamber size( mm) <1>230*370 3 Chamber capacity (L) 16L 4 Product classification N 5 Input power (VA) 1800VA 6 Design pressure (MPa) -0.1/0.28MPa 7 Design temperature ("C) 140"C 8 Temperature display accuracy 0.1·c ("C) 9 Pressure display accuracy (kPa) 1kPa 10 One cycle water consumption(mL) 400 mL11 Environment temperature ("C) +5"C~40"C 12 Relative humidity range ≤85%13 Net weight (kg) 26 kg 14 Max load(kg) 31kg 15 Noise 70dBA 16 Max. instrument load 4.5kg 17 Max. fabrics articles load 2.5kg 18 Single package max weight 1.5kg Voltage 110V-/120V- 230V-240V Fuse parameter F20AL250V F12AL250V * Sterilization temperature: 121oC/20min, 134oC/6min

• The product is composed by sterilization chamber, thermal-protective coating, door assemblies, solenoid valve, piping system, electrical system, main board, control board and shell.
• Automatic safety valve: Safety valve will release the pressure when the pressure is over the set value.
• With a water tank of 5-6L, one tank of water can be used for 15 sterilization cycles.
• 1800W heating elements, speed up the heating, more efficient.
• Heat protector: Chamber have heat protector.
